Special Noble Metal Thermocouples
We produce and create assemblies for rare metal thermocouples. Platinum and rhodium alloy conductors are used to make platinum rhodium thermocouples, which can measure temperatures up to +1800 °C. Because of their sturdy design, they are ideal for demanding industrial application.
The ideal operating temperature range is between 1200 and 1800 °C.
| Type | Description | Standard | Class | Deviation Range Occured [At 1200 Deg. C] |
|---|---|---|---|---|
| R | Pt/PtRh13% | IEC 60584 P.2 / ASTM E230 | 1 & 2 | +/-1 degrees TO 0.25% * OT |
| S | Pt/PtRh10% | IEC 60584 P.2 / ASTM E230 | 1 & 2 | +/-1 degrees TO 0.25% * OT |
| B | Pt30%Rh-Pt6%Rh | IEC 60584 P.2 / ASTM E230 | 1 & 2 | +/-1 degrees TO 0.25% * OT |
| • Available in Configurations as | : | Simplex , Duplex & Triplex configurations. |
| • Available in Options as | : | With flange, with thermowells, zirconia, ceramic, tungsten-carbide coatings as per specifications & user drawings. |
| • Available in Designs as | : | Head Type, Connector Type, L-Shaped, Mineral Insulated. With different designs & configurations, the buyer is capable to choose from various sheathing options as well. These include High-Alumina ceramic, SS, Inconel, Silicon-Nitride, Silicon-Nitride-Bonded (for zinc, aluminum, copper & molten metal applications) and more. This ofcourse depends on the requirement, application and material involved in the process. |
